Core Features

• Lightweight Aluminum Alloy Body

  High-quality die-cast aluminum alloy housing with an exquisite appearance, excellent heat dissipation, stable load capacity, compact size and light weight, greatly saving installation space.
• Multi-directional Mounting + Flexible Combination

  Hollow output shaft structure supports multi-orientation installation and is compatible with various input/output methods, enabling fast integration with motors and transmission mechanisms for exceptional adaptability.
• Smooth Transmission & Low Noise

  Precision meshing of worm gears ensures stable operation, minimal vibration and low noise, making it ideal for equipment requiring high quietness.
• Wide Ratio Range & Easy Selection

  Frame sizes: 30/40/50/63; transmission ratios: 7.5–100; supports single-stage/two-stage combinations, matching standard motors from 0.06–1.5kW.
• Reliable & Durable with Simple Maintenance

  Reliable sealing, economical and long-lasting; oil change after the first 400 operating hours, then approximately every 4000 hours, resulting in low daily maintenance costs.

Small automated equipment, conveyor lines, packaging machinery, food machinery, printing machinery, office and medical equipment, and other applications demanding compact size, low noise and flexible installation.

Quality Assurance

Intelligent Production

Global Service

Green & High-Efficiency

• Determine the model based on torque, transmission ratio, output speed and mounting type.
• The standard motor is three-phase 4-pole 380V/50Hz. Custom motors such as brake, variable frequency and explosion-proof types are available.
• Specify accessories including output flange (F/FL), output shaft (DZ single shaft / SZ double shaft), torque arm (TA), extended shaft (YZ/RB), etc.
• Standard products are in stock for fast delivery. Special transmission ratios / structures can be custom designed and manufactured.
