WUMA is one of the earliest manufactures of worm gear boxes in China, now our gear boxes are hot selling to more than 80 countries.
Worm gear box is a type of reduction gear unit that is used for converting high speed input of motor into lower speed output while also maintaining high torque.
The inner structure of worm gear box consists of a gear in the form of a screw meshed into the machine which outputs in the right angle orientation.
The housing of the stainless steel worm gear reducer is made of stainless steel instead of traditional cast iron, making it more suitable for special working environments with corrosion, high temperature, high pressure and high humidity.
Type |
Worm Gear Boxes / Stainless Steel Worm Gearbox |
Housing |
304 |
Worm gear |
Tin bronze |
Output hub |
304 |
Lubricant |
Synthetic oil |
Oil seal |
Viton seal (Standard) |
Protection grade |
IP65,IP69K |
Model |
WMSS 30/40/50/63 |
Ratio |
7.5/10/15/20/25/30/40/50/60/80/100 |
Package |
Carton, Honey Comb Carton, Wooden Pallet |
Usage |
Industrial Machine, Food Stuff, Ceramics, Chemical, Packing, Dyeing, Wood Working, Glass, etc. |
Flange |
IEC flange or NEMA flange |
1.Common mounting dimensions.
2.A smooth surface enabling easy cleaning
3.Corrosion resistance
4.Wide range of accessories.
5.The housing features high strength and can be applied to various special working environments, such as coastal areas or around chemical plants.
Welcome to Wuma , a manufacturer committed to developing and manufacturing various types of gear reducers and gearmotors for the field of gear transmission.
